| 입력 전압: | AC 100~240V 50/60Hz | 시야 각도: | 178/178' |
|---|---|---|---|
| 대비율: | 3000:1 | 화소 피치: | 0.53(H)x0.53(V)mm |
| 생활 시간: | 60000hrs | 외부 통제: | RS232 |
| 이름: | 디스플레이 패널 와이파이 광고 선수를 접합하는 HD 큰 텔레비전 모니터 화면 LCD | 임명 방법: | 내각 / 플로어 스탠딩 / 앞 유지 / 벽걸이용 |
| 강조하다: | 1920x1080 LCD 짜집기 패널,700 cd/m2 LCD 짜집기 패널,RS232 HD 텔레비전 모니터 화면 |
||
LVDS RS232 700cd/m² 1920x1080 LCD Splicing Video Wall Display Panel
Key Features
Original industrial DID LCD panel
Straight-down LED backlight system.
16.7M COLOR
178° wide vision angle.
Response time: ≤ 6ms.
Easy-going MD (modular design)
Multi-layer menu display.
7*24 uninterrupted working.
Ample built-in signal interface
Advantages of LCD Video Wall
1, Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
2,High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
3,Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
4, Low power consumption and low heat radiation
5,Long service life lowers the cost of usage and maintenance
6,Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
7,Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
8,Economical and practical: High performance and high quality make it cost less.
| Panel Size | 55" LCD Screen |
| Backlight Type | LED |
| Display Area | 1209.6(H)x680.4(v)mm |
| Aspect Ratio | 16:9 |
| Max Resolution | 1920X1080 |
| Color | 8Bit,16.7M |
| Brightness (nits) | 700cd/m2 |
| Contrast | 1400:1 |
| Visual Angle (H/V) | 178/178 ° |
| Response Time | 8 ms |
| Life Span | >60,000 hours |
| Bezel width (between screens) | 1.8mm |
| Product Dimension | 1211.5(L)*682.3(H)*85.8(D) |
| Product Weight | 24KG |
| Interfaces (option 1- without 4K input) | |
| Model No. | TYL-DP5509 |
| Input | 1*DVI |
| 1*Support HDMI Input | |
| 1*VGA (SVGA / XGA / WXGA) | |
| 1*BNC (PAL/NTSC) | |
| 1*RS232(RJ45) | |
| Output | 2*RS232(RJ45) |
| 1*BNC (PAL/NTSC) | |
| Interfaces (option 2- With 4K input) | |
| Model No. | TYL-DP5515-H4 |
| Input | 1*DVI |
| 1*Support HDMI Input | |
| 1* DP (Display port) | |
| 1*VGA (SVGA / XGA / WXGA) | |
| 1*RS232(RJ45) | |
| Output | 1* DP (Display port) |
| 1*RS232(RJ45) | |
| Power | |
| Power Supply | AC100V~240V 50/60Hz |
| Maximum Power Consumption | 210W |
| Standby Power Consumption | <3W |
| Working Environment | |
| Working Temperature | 0℃~60℃ |
| Working Humidity | 5%-95%RH |
FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
